ٍSystem Parameters/FMB120 SMS Commands
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
138 | Uint8 | 0 | 0 | 8 | 1 – Ignition | Movement source |
2 – Accelerometer |
4 – GNSS |
8 – CAN Speed |
133 | Uint8 | 0 | 0 | 1 | 0 – GNSS | Speed Source |
1 – OBD / CAN |
106 | Uint8 | 1 | 0 | 1 | 0 – Disable | Static navigation |
1 – Enable |
112 | Uint8 | 1 | 0 | 3 | 1 – Movement | Static navigation source |
2 – Ignition |
3 – Movement and Ignition |
107 | Uint8 | 2 | 0 | 2 | 0 – After Position Fix | Send/Save records without TS |
1 – Always |
2 – After Time Sync |
108 | Uint8 | 1 | 0 | 1 | 0 – Disable | LED Indication |
1 – Enable |
109 | Uint8 | 10 | 1 | 15 | 0 – Undefined | GNSS source |
1 – Beidou only |
2 – Glonass only |
3 – Glonass and Beidou not allowed |
4 – Galileo only |
5 – Galileo and Beidou |
6 – Galileo and Glonass |
7 – Galileo, Glonass and Beidou not allowed |
8 – Gps only |
9 – Gps and Beidou |
10 – Gps and Glonass |
11 – Gps, Glonass and Beidou not allowed |
12 – Gps and Galileo |
13 – Gps, Galileo and Beidou |
14 – Gps, Galileo and Glonass |
15 – Gps, Galileo, Glonass and Beidou and not allowed |
110 | Uint8 | 0 | 0 | 1 | 0 – On need | Battery charge mode |
1 – After ignition on |
113 | Uint8 | 0 | 0 | 1 | 0 – Codec 8 | Data Protocol |
1 – Codec 8 Extended |
135 | Uint8 | 0 | 0 | 1 | 0 – DIN2/AIN1 | Input mode |
1 – Ground Sense |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
102 | Uint8 | 2 | 0 | 4 | 0 – Disable | Sleep settings |
1 – GPS sleep |
2 – Deep sleep |
3 – Online Deep sleep |
4 – Ultra Deep sleep |
6 – Power Off sleep (only for FMB965) |
103 | Uint16 | 1 | 1 | 3000 | Minutes | Timeout |
| | | | | | |
| | | | | | |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
101 | Uint8 | 4 | 1 | 14 | 1 – DIN 1 | Ignition settings |
2 – Accelerometer |
3 – Digital Input or Accelerometer |
4 – Power Voltage |
5 – Digital Input or Power Voltage |
6 – Accelerometer or Power Voltage |
7 – Digital Input, Accelerometer, or Power Voltage |
8 – Engine RPM |
9 – Digital Input or Engine RPM |
10 – Accelerometer or Engine RPM |
11 – Digital Input, Accelerometer or Engine RPM |
12 – Power Voltage or Engine RPM |
13 – Digital Input, Power Voltage or Engine RPM |
14 – Accelerometer, Power Voltage or Engine RPM |
104 | Uint16 | 30000 | 0 | 30000 | mV | High voltage |
105 | Uint16 | 13200 | 0 | 29999 | mV | Low voltage |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
19001 | Uint16 | 5 | 1 | 60 | Seconds | Movement Start Delay |
19002 | Uint16 | 60 | 5 | 300 | Seconds | Movement Stop Delay |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
900 | Uint8 | 1 | 0 | 3 | 0 – Gps only | Synchronization settings |
1 – NITZ and NTP |
2 – NTP |
3 – NITZ |
901 | Uint8 | 0 | 0 | 24 | Hours | NTP Resync |
902 | Char | “avl1.teltonika.lt” | 0 | 55 | String | NTP server 1 |
903 | Char | “pool.ntp.org” | 0 | 55 | String | NTP server 2 |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
169 | Uint8 | 2 | 0 | 2 | 0 – Disabled | Accelerometer Auto Calibration |
1 – Once |
2 – Continuous |
170 | Uint8 | 1 | 0 | 1 | 0 Disabled | Gravity Filter |
1 Enabled |
FMB120 System Sarameters SMS CommandsٍGPRS Parameter/FMB120 SMS Commands
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
1000 | Uint32 | 300 | 30 | 259200 | Seconds | Open link timeout |
1001 | Uint16 | 30 | 5 | 300 | Seconds | Response timeout |
1002 | Uint8 | 0 | 0 | 1 | 0 – Newest | Sort by |
1 – Oldest |
1003 | Uint16 | 0 | 0 | 300 | Seconds | Network ping timeout |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
2000 | Uint8 | 1 | 0 | 1 | 0 – Disable | GPRS context |
1 – Enable |
2001 | Char | “” | 0 | 32 | String | APN |
2002 | Char | “” | 0 | 32 | String | APN username |
2003 | Char | “” | 0 | 32 | String | APN password |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
2004 | Char | “” | 0 | 55 | String | Domain |
2005 | Uint16 | 0 | 0 | 65535 | Number | Port |
2006 | Uint8 | 1 | 0 | 1 | 0 – TCP | Protocol |
1 – UDP |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
2010 | Uint8 | 0 | 0 | 3 | 0 – Disable | Backup Server Mode |
1 – Backup |
2 – Duplicate |
3 – EGTS |
2007 | Char | “” | 0 | 55 | String | Backup Server Domain |
2008 | Uint16 | 0 | 0 | 65535 | Number | Backup Server Port |
2009 | Uint8 | 0 | 0 | 1 | 0 – TCP | Backup Server Protocol |
1 – UDP |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
13003 | Uint8 | 1 | 0 | 1 | 0 – Disable | FOTA WEB Status |
1 – Enable |
13000 | Char | fm.teltonika.lt | 0 | 55 | String | FOTA WEB Domain |
13001 | Uint16 | 5000 | 0 | 65535 | Number | FOTA WEB Port |
13002 | Uint16 | 720 | 30 | 65535 | Number | FOTA WEB Period |
GPSR Parameters/FMB120 SMS CommandsSMS-Call Settings/FMB120 SMS Commands
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
3000 | Uint8 | 0 | 0 | 1 | 0 – Disable | Allow SMS data sending |
1 – Enable |
3001 | Char | “” | 0 | 16 | String | Data Send Number |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
3003 | Char | “” | 0 | 5 | String | Login |
3004 | Char | “” | 0 | 5 | String | Password |
3006 | Uint16 | UTC+00:00 | UTC-12:00 | UTC+13:00 | Time zone | SMS event Time Zone |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
3005 | Uint8 | 0 | 0 | 4 | 0 – Do nothing | Incoming call action |
1 – Hangup |
2 – Report position |
3 – Spy call |
4 – Auto answer |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
3007 | Uint8 | 0 | 0 | 7 (3 for FMB125) | 0 – Disable | Outgoing call trigger |
1 – DIN1 |
2 – Crash event |
3 – DIN1 and Crash event |
4 – DIN2 |
5 – DIN1 and DIN2 |
6 – DIN2 and Crash event |
7 – DIN1, DIN2 and Crash event |
3008 | Uint8 | 0 | 0 | 10 | GSM number | GSM number index |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
4000-4199 | Char | “” | 0 | 16 | String | Authorized number |
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
6000-6009 | Char | “” | 0 | 16 | String | Predefined number |
SMS-Call/FMB120 SMS CommandsGSM Operators/FMB120 SMS Commands
Parameter ID | Parameter Type | Default value | Value range | Value | Parameter name |
Min | Max |
5000-5049 | Uint32 | 0 | 0 | 999999 | Number | SIM1 roaming operator list |
9500-9549 | Uint32 | 0 | 0 | 999999 | Number | SIM2 roaming/home operator list |
5500-5549 | Uint32 | 0 | 0 | 999999 | Number | Operator blacklist |
GMS Operators/FMB120 SMS CommandsData Acquisition Mode Parameters/FMB120 SMS Commands
Home Network GSM operator code “Vehicle on STOP” parameters
Parameter ID | Parameter Type | Default value | Value range | Parameter name |
Min | Max |
10000 | Uint16 | 3600 | 0 | 2592000 | Min Period |
10004 | Uint8 | 1 | 1 | 255 | Min Saved Records |
10005 | Uint16 | 120 | 0 | 2592000 | Send Period |
Home Network GSM operator code “Vehicle on STOP” parametersHome Network GSM operator code “Vehicle MOVING” parameters
Parameter ID | Parameter Type | Default value | Value range | Parameter name |
Min | Max |
10050 | Uint16 | 300 | 0 | 2592000 | Min Period |
10051 | Uint16 | 100 | 0 | 65535 | Min Distance |
10052 | Uint8 | 10 | 0 | 180 | Min Angle |
10053 | Uint8 | 10 | 0 | 100 | Min Speed Delta |
10054 | Uint8 | 1 | 1 | 255 | Min Saved Records |
10055 | Uint16 | 120 | 0 | 2592000 | Send Period |
Home Network GSM operator code “Vehicle MOVING” parametersRoaming Network GSM operator code “Vehicle on STOP” parameters
Parameter ID | Parameter Type | Default value | Value range | Parameter name |
Min | Max |
10100 | Uint16 | 3600 | 0 | 2592000 | Min Period |
10104 | Uint8 | 1 | 1 | 255 | Min Saved Records |
10105 | Uint16 | 0 | 0 | 2592000 | Send Period |
Roaming Network GSM operator code “Vehicle on STOP” parametersRoaming Network GSM operator code “Vehicle MOVING” parameters
Parameter ID | Parameter Type | Default value | Value range | Parameter name |
Min | Max |
10150 | Uint16 | 300 | 0 | 2592000 | Min Period |
10151 | Uint16 | 100 | 0 | 65535 | Min Distance |
10152 | Uint8 | 10 | 0 | 180 | Min Angle |
10153 | Uint8 | 10 | 0 | 100 | Min Speed Delta |
10154 | Uint8 | 1 | 1 | 255 | Min Saved Records |
10155 | Uint16 | 0 | 0 | 2592000 | Send Period |
Roaming Network GSM operator code “Vehicle MOVING” parametersUnknown Network GSM operator code “Vehicle on STOP” parameters
Parameter ID | Parameter Type | Default value | Value range | Parameter name |
Min | Max |
10200 | Uint16 | 3600 | 0 | 2592000 | Min Period |
10204 | Uint8 | 1 | 1 | 255 | Min Saved Records |
10205 | Uint16 | 120 | 0 | 2592000 | Send Period |
Unknown Network GSM operator code “Vehicle on STOP” parametersUnknown Network GSM operator code “Vehicle MOVING” parameters
Parameter ID | Parameter Type | Default value | Value range | Parameter name |
Min | Max |
10250 | Uint16 | 300 | 0 | 2592000 | Min Period |
10251 | Uint16 | 100 | 0 | 65535 | Min Distance |
10252 | Uint8 | 10 | 0 | 180 | Min Angle |
10253 | Uint8 | 10 | 0 | 100 | Min Speed Delta |
10254 | Uint8 | 1 | 1 | 255 | Min Saved Records |
10255 | Uint16 | 0 | 0 | 2592000 | Send Period |
Unknown Network GSM operator code “Vehicle MOVING” parametersTeltonika FMB120 Wiring Diagram & Scheme
FMB120 Wiring Diagram
FMB120 Scheme المصدر: Teltonika-gps.com
