اكواد جهاز التتبع FMB920 SMS Commands
طريقة تفعيل جهاز تتبع المركبات عن طريق الرسائل النصية FMB920 SMS Commands ويعتبر جهاز FMB920 الأخ الأصغر لجهاز FMB120 من شركة Teltonika ويتميز بصغر حجمه وصلابته لتفعيل أجهزة التتبع والحصول على برنامج تتبع مميز تواصل معنا على واتساب +966570960313 طريقة إرسال الأوامر بالرسائل النصية: <login><space><password><space>setparam (في حال عدم وجود اسم مستخدم وكلمة مرور ادخل مسافتين قبل الأمر) FMB920 SMS Commands: GPRS Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 1000 Uint32 300 30 259200 Seconds Open link timeout 1001 Uint16 30 5 300 Seconds Response timeout 1002 Uint8 0 0 1 0 – Newest Sort by 1 – Oldest 1003 Uint16 0 0 300 Seconds Network ping timeout Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 2000 Uint8 1 0 1 0 – Disable GPRS context 1 – Enable 2001 Char “” 0 32 String APN 2002 Char “” 0 32 String APN username 2003 Char “” 0 32 String APN password Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 2004 Char “” 0 55 String Domain 2005 Uint16 0 0 65535 Number Port 2006 Uint8 1 0 1 0 – TCP Protocol 1 – UDP Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 2010 Uint8 0 0 3 0 – Disable Backup Server Mode 1 – Backup 2 – Duplicate 3 – EGTS 2007 Char “” 0 55 String Backup Server Domain 2008 Uint16 0 0 65535 Number Backup Server Port 2009 Uint8 0 0 1 0 – TCP Backup Server Protocol 1 – UDP Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 13003 Uint8 1 0 1 0 – Disable FOTA WEB Status 1 – Enable 13000 Char fm.teltonika.lt 0 55 String FOTA WEB Domain 13001 Uint16 5000 0 65535 Number FOTA WEB Port 13002 Uint16 720 30 65535 Number FOTA WEB Period GPRS FMB920 SMS Commands إقرأ أيضا: FMB920 SMS Commands: System Paramaters Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 138 Uint8 0 0 8 1 – Ignition Movement source 2 – Accelerometer 4 – GNSS 8 – CAN Speed 133 Uint8 0 0 1 0 – GNSS Speed Source 1 – OBD / CAN 106 Uint8 1 0 1 0 – Disable Static navigation 1 – Enable 112 Uint8 1 0 3 1 – Movement Static navigation source 2 – Ignition 3 – Movement and Ignition 107 Uint8 2 0 2 0 – After Position Fix Send/Save records without TS 1 – Always 2 – After Time Sync 108 Uint8 1 0 1 0 – Disable LED Indication 1 – Enable 109 Uint8 10 1 15 0 – Undefined GNSS source 1 – Beidou only 2 – Glonass only 3 – Glonass and Beidou not allowed 4 – Galileo only 5 – Galileo and Beidou 6 – Galileo and Glonass 7 – Galileo, Glonass and Beidou not allowed 8 – Gps only 9 – Gps and Beidou 10 – Gps and Glonass 11 – Gps, Glonass and Beidou not allowed 12 – Gps and Galileo 13 – Gps, Galileo and Beidou 14 – Gps, Galileo and Glonass 15 – Gps, Galileo, Glonass and Beidou and not allowed 110 Uint8 0 0 1 0 – On need Battery charge mode 1 – After ignition on 113 Uint8 0 0 1 0 – Codec 8 Data Protocol 1 – Codec 8 Extended 135 Uint8 0 0 1 0 – DIN2/AIN1 Input mode 1 – Ground Sense Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 102 Uint8 2 0 4 0 – Disable Sleep settings 1 – GPS sleep 2 – Deep sleep 3 – Online Deep sleep 4 – Ultra Deep sleep 6 – Power Off sleep (only for FMB965) 103 Uint16 1 1 3000 Minutes Timeout Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 101 Uint8 4 1 14 1 – DIN 1 Ignition settings 2 – Accelerometer 3 – Digital Input or Accelerometer 4 – Power Voltage 5 – Digital Input or Power Voltage 6 – Accelerometer or Power Voltage 7 – Digital Input, Accelerometer, or Power Voltage 8 – Engine RPM 9 – Digital Input or Engine RPM 10 – Accelerometer or Engine RPM 11 – Digital Input, Accelerometer or Engine RPM 12 – Power Voltage or Engine RPM 13 – Digital Input, Power Voltage or Engine RPM 14 – Accelerometer, Power Voltage or Engine RPM 104 Uint16 30000 0 30000 mV High voltage 105 Uint16 13200 0 29999 mV Low voltage Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 19001 Uint16 5 1 60 Seconds Movement Start Delay 19002 Uint16 60 5 300 Seconds Movement Stop Delay Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 900 Uint8 1 0 3 0 – Gps only Synchronization settings 1 – NITZ and NTP 2 – NTP 3 – NITZ 901 Uint8 0 0 24 Hours NTP Resync 902 Char “avl1.teltonika.lt” 0 55 String NTP server 1 903 Char “pool.ntp.org” 0 55 String NTP server 2 Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 169 Uint8 2 0 2 0 – Disabled Accelerometer Auto Calibration 1 – Once 2 – Continuous 170 Uint8 1 0 1 0 Disabled Gravity Filter 1 Enabled FMB920 SMS Commands System Parameters FMB920 SMS Commands: SMS & CALL Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 3000 Uint8 0 0 1 0 – Disable Allow SMS data sending 1 – Enable 3001 Char “” 0 16 String Data Send Number Parameter ID Parameter Type Default value Value range Value Parameter name Min Max 3003 Char “” 0 5 String Login 3004 Char “” 0 5 String Password 3006 Uint16 UTC+00:00 UTC-12:00 UTC+13:00 Time zone SMS event
